Description
SERIES 13 FIBERGLASS TYPE CABLE TRAY
– 3″ NOMINAL OUTSIDE DEPTH
– 2″ NEMA LOADING DEPTH
– LOADING – NEMA 8C TESTED PER NEMA FG-1,
12″ RUNG SPACING
– UTILIZES 9*-4003 SPLICE PLATES WITH SS6
(316 STAINLESS STEEL) HARDWARE
Specifications:
- 13 = FRP SERIES 13 3″ HEIGHT CABLE TRAY
- Material: Polyester
- Rung Spacing: 12″ RUNG SPACING
- Width: 18″
- Length: 120″
TO DETERMINE DEFLECTION (INCHES) AT ANY LESSER LOAD, MULTIPLY THE ACTUAL LOAD (LBS/FT) BY THE DEFLECTION MULTIPLIER)
NOTE: VALUES ARE BASED ON SIMPLE BEAM TESTS PER NEMA VE-1 ON 36″ WIDE CABLE TRAY WITH RUNGS SPACED ON 12″ CENTERS. THE
PUBLISHED LOAD SAFETY FACTOR IS 1.5. TO CONVERT 1.5 SAFETY FACTOR TO 2.0, MULTIPLY THE PUBLISHED LOAD BY 0.75. TO OBTAIN MIDSPAN DEFLECTION, MULTIPLY THE LOAD BY THE DEFLECTION MULTIPLIER. CABLE TRAY MUST BE SUPPORTED ON SPANS SHORTER THAN OR
EQUAL TO THE LENGTH OF THE TRAY.
