Size Range: 5/8″-11 thru 11/2″-6 rod
Function: Designed to be embedded in concrete to provide
a point of support for 5/8″-11 thru 11/2″-6 rod or bolt sizes .
Finish: Plain anchor bolt with Electro-Galvanized coupling.
Contact B-Line for alternative finishes and materials.
Note: For rod sizes 3/8″-16 and 1/2″-13, refer to B2501
see page 198.
Order By: Part number and rod size.
For 11/8″-7, 11/4″-6, and 11/2″-6 consult factory.
